Standalone Smart Switch Series (GS728TPP)
24-Port Gigabit PoE+ Ethernet Smart Switch with 4 Dedicated 4 SFP Uplink Ports (384W)
Standalone Smart Switch Series (GS728TPP)
24-Port Gigabit PoE+ Ethernet Smart Switch with 4 Dedicated 4 SFP Uplink Ports (384W)
NETGEAR Smart Switches offer powerful L2 and L2+/Layer 3 Lite features, better PoE functionality, and enhanced performance and usability.
Features
Traffic Management
Auto Negotiation of speed and duplex modes
IEEE 802.3x Flow Control
Dynamic MAC address management
IEEE 802.1Q-based VLAN
Auto Voice VLAN
Auto Video VLAN (selected models)
VLAN routing (selected models)
QoS based on WRR, strict priority, or both
Port-based and IEEE 801.2p-based QoS
TCP/UDP-based QoS
DiffServ
DSCP Support
Rate Limiting (ingress, or egress)
Link Aggregation and LACP
Switch Management
Web browser-based management GUI
Smart Control Center Software for multi-switch management
IP Access List
IPv6 Management
Configurable Management VLAN
SNMP v1/v2c and v3
Standard MIBs (RFC1213, RFC1643, and RFC1493)
RMON group 1, 2, 3, 9
Firmware Upgrade through Smart Control Center (TFTP)
Firmware download (to switch) and upload (to server) through TFTP/HTTP
Configuration and Image Upload (to PC) through HTTP
Configuration Download (to Switch) thru TFTP/HTTP and upload (to server)
Memory & FLASH log
Syslog (server)
System password protection
Security
MAC lockdown by number of MACs
IEEE 802.1x port authentication
IEEE 802.1x port authentication
Dynamic VLAN Assignment
Guest VLAN
TACACS+
3 HTTPS /SSL versions
TLS session
Trusted MAC
IPv4, L4-based Access Control List (ACL)
IPv6-based ACL
Spanning Tree, Routing and Stacking
IEEE 802.1D, IEEE 802.1w RSTP and MSTP
Option to enable/disable BPDU flooding when STP is disabled
Static routing with 32 static routes (Selected models)
Hosted ARP table size of 1,024 (Selected models)
Reliability, Performance and Troubleshooting
Port mirroring both on ingress and egress traffic
Jumbo frame support
Broadcast Storm control
Cable diagnostics
Loop Detection
DoS Prevention
IEEE 802.1ab LLDP
LLDP-MED
Dual Image
SNTP
Option to enable/disable the flooding of EAPOL when 802.1x is disabled
Protected ports
DNS client (except FS526T/FS728TLP/FS750T2)
DHCP clients
DHCP snooping (except FS526T/FS728TLP/FS750T2)
Ping and traceroute client (except FS526T/FS728TLP/FS750T2)
Energy Efficient Ethernet (IEEE 802.3az) compliant (Selected models)
Power savings with short cable detection (GS752TXS only) and auto power-down when ports are in idle mode
Technical Specifications
- Weight (kg) : 4.36kg
- Dimensions (WxDxH) mm : 440 x 257 x 44
- Gigabit ports : 24
- SFP ports : 4
- Number of PoE ports : 24
- PoE+ (802.3at) ports : 24
- Total PoE Power budget (Watts) : 384w
- Max MAC entries : 8K
- Buffer size : N/A
- VLAN (Number Supported) : 256
- VLAN routing : Yes
- Dynamic VLAN assignment : Yes
- MLD Snooping : Yes
- Static route : 32
- Host ARP table : 1024 in Switch mode, approximately 100 in Router mode
- EEE : Yes
- DoS Prevention : N/A
- Internal/External : Internal 100-240VAC ~ 50-60Hz
- Max consumption (Watts) : 483.5w
- FAN : 2
- Acoustic Noise Level @25C (dBA) : 31.8
- Operating Temperature : 0° to 50° C
- MTBF : 247163.4 hrs
- Warranty: This product is backed by a NETGEAR 5-year Hardware Warranty .
- 5-year Next Business Day Hardware Replacement. Click here for coverage, availability and terms and conditions.
- Support : ProSUPPORT 24x7 Advanced Technical Support via phone, email and chat for 90 days (Remote diagnostics performed by our technical experts for prompt resolution of technical issues). ProSUPPORT coverage can be extended by purchasing one, three, or five year contracts.
- GS728TPP Support
